FRAME
Specialized M5 Aluminum, 29 Trail HT Geometry, integrated down tube battery, enclosed internal cable, Command Post routing, 148mm spacing
FORK
SR Suntour XCM32, 47mm offset, 15x110mm thru-axle, 100mm travel
SEAT BINDER
Alloy, bolt-type, 34.9mm
STEM
Specialized, 3D-forged alloy, 4-bolt, 6-degree rise, 31.8mm clamp
HANDLEBARS
Specialized Trail, 6061 alloy, 8-degree backsweep, 6-degree upsweep, 27mm rise, 31.8mm clamp, XS 720mm, S-XL 750mm,
GRIPS
Specialized Body Geometry XC, clamp-on
SADDLE
Body Geometry Myth 155 XS, Body Geometry Henge 143 S/M/L/XL, steel rails
SEATPOST
Specialized 2-bolt head, forged alloy, 8mm offset, micro-adjust, 30.9mm
FRONT BRAKE
Shimano BR-MT200, hydraulic disc, 180mm
REAR BRAKE
Shimano BR-MT200, hydraulic disc, 160mm
REAR DERAILLEUR
Shimano Acera, RapidFire Plus, 9-speed
SHIFT LEVERS
Shimano Alivio, 9-speed w/ Optical Gear Display
CHAIN
KMC e9S.NPBK, e-bike chain, 9-speed w/ Missing Link™
CRANKSET
Custom alloy forged crankarms
FRONT WHEEL
Hand-built wheel assembly
REAR WHEEL
Hand-built wheel assembly
RIMS
Stout XC 29, 25mm internal width, disc-specific
FRONT HUB
Specialized, sealed cartridge bearings, 15x110mm spacing, 28h
REAR HUB
Specialized, sealed cartridge bearings, 12x148mm thru-axle, 32h
FRONT TIRE
Ground Control, GRID casing, GRIPTON® compound, 2Bliss Ready, 29x2.3"
REAR TIRE
Ground Control, GRID casing, GRIPTON® compound, 2Bliss Ready, 29x2.3"
INNER TUBES
Standard, Presta valve
SPOKES
Stainless, 14g
MOTOR
Specialized 1.2 E, custom Rx Street-tuned motor, 250W nominal
WIRING HARNESS
Custom Specialized wiring harness
BATTERY
Specialized M1-400, integrated Trail Display, ANT+/Bluetooth® module, 400Wh
CHARGER
Custom Specialized 42V2A Charger w/ Rosenberger plug, AC power cord included
